Powerful stand-disperser (Ecoline), flexible-use disperser with EU-power cable (230 V).PT 10-35 GT features high drive power and sleek design. With its large reserve capacity, it can be used for a sample with large volumes as easily as preparing samples with small volumes.
Drive Unit EU type E+F (CEE7/7) power cable
| Min. Volume (ml) | 0.1 |
|---|---|
| Max. Volume (ml) | 10000 |
| Power (W) | 1200 |
| Tip speed | Up to max. 34 m/s |
| Applicable aggregates | ø 5 mm to ø 36 mm |
| Speed range | 500 – 30,000 rpm |
| Drive coupling | Aggregates with F coupling |
| Noise level (drive without aggregate) | 75 dB(A) at 25,000 rpm 82 dB(A) at 30,000 rpm |
| Motor | Universal with carbon brushes |
| Connection voltage | 90 – 230 V ± 10%, 50 Hz / 60 Hz |
| Relative humidity (max.) | 80% during storage / 80% during operation |
| Operating temperature | 0 – 40 °C |
| Protection class acc. to DIN | IP 20 |
| Dimensions (L × W × H) | Drive: 95 × 210 × 247 mm |
| Weight | Drive: 3200 g |
| EMC standards | IEC / EN 61000-6-2 / EN 61000-6-3 |
| Safety standard | IEC / EN 61010-2-51 |
